0191-12XXTH

PCB Terminal BlocksPCB Connector-Socket

Pitch : 5.00mm, 300V, 5A

AccessoriesPDF Download Inquiry Add

CAD data

General information Material information Connection data-IEC Connection data-UL Environment & Safety UL Recognized CUL Recognized
  •
    General information
    • Short description
    • PCB Connector
    • Long description
    • PCB Connector–Socket, Reflow soldering, Pitch:5.00mm, 300V, 2A
    • Category
    • PCB Connector–Socket
    • Pitch (mm)
    • 5.00
    • Color
    • Black (default)
    • Type of locking
    • Without
    • Soldering method
    • Reflow Soldering (Temperature condition according to standard IPC/JEDEC J-STD-020E)
    • Length (mm)
    • 5.00*P
    • Width (mm)
    • 2.8
    • Height (mm)
    • 16.5
    • Pin demensions (Thickness x Width)(mm)
    • 1.3
    • PCB hole diameter (mm)
    • 1.6
    • Number of positions
    • 02P~20P
    • Level
    • Single level
  •
    Material information
    • Insulation material
    • HIGH-TEMPERATURE PLASTICS
    • Insulation material group
    • IIIa
    • Flame retardant rating , compliant with UL94
    • V0
    • Insulation resistance
    • ≥500MΩ at DC 500V
    • Conductor material
    • COPPER ALLOY
    • Plating of conductor surface
    • Tin PLATED
    • MSL
    • 4
  •
    Connection data-IEC
    • Rated voltage (V)
    • 320
    • Rated current (A)
    • 4
    • Rated voltage (II/2)(V)
    • 630
    • Rated voltage (III/2) (V)
    • 320
    • Rated voltage (III/3)(V)
    • 250
    • Rated impulse voltage (II/2)(KV)
    • 4
    • Rated impulse voltage (III/2)(KV)
    • 4
    • Rated impulse voltage (III/3)(KV)
    • 4
  •
    Connection data-UL
    • Rated voltage (UL/CUL Group B)(V)
    • 300
    • Rated current (UL/CUL Group B)(A)
    • 5
    • Rated voltage (UL/CUL Group D)(V)
    • 300
    • Rated current (UL/CUL Group D)(A)
    • 5
  •
    Environment & Safety
    • Operating temperature. max (°C)
    • 120
    • Operating temperature. min (°C)
    • -40
  •
    UL Recognized
    • Rated voltage (Group B)(V)
    • 300
    • Rated current (Group B)(A)
    • 5
    • Rated voltage (Group D)(V)
    • 300
    • Rated current (Group D)(A)
    • 5
  •
    CUL Recognized
    • Rated voltage (Group B)(V)
    • 300
    • Rated current (Group B)(A)
    • 5
    • Rated voltage (Group D)(V)
    • 300
    • Rated current (Group D)(A)
    • 5

The web catalog is for reference only. Dinkle remains the right of product modification and engineering change of the design. The final product is made according to engineering drawing.
