General information
- Short description
- PCB Connector – Socket, Wave soldering
- Long description
- PCB Connector – Socket, Wave soldering, Pitch:5.08mm, 300V, 20A
- Category
- PCB Connector – Socket
- Pitch (mm)
- 5.08
- Color
- Green (default)
- Type of locking
- Without
- Soldering method
- Wave soldering
- Length (mm)
- 5.08*(P-1)+6.68
- Width (mm)
- 8.47
- Height (mm)
- 12
- Pin demensions (Thickness x Width)(mm)
- 1.0x1.0
- PCB hole diameter (mm)
- 1.6~1.7
- Number of positions
- 02P~24P
- Level
- Single level
-
Material information
- Insulation material
- PA
- Insulation material group
- I
- Flame retardant rating , compliant with UL94
- V0
- Insulation resistance
- ≥500MΩ at DC 500V
- Conductor material
- COPPER ALLOY
- Plating of conductor surface
- Tin PLATED
-
Connection data-IEC
- Rated voltage (V)
- 630
- Rated current (A)
- 24
- Rated voltage (II/2)(V)
- 630
- Rated voltage (III/2) (V)
- 320
- Rated voltage (III/3)(V)
- 320
- Rated impulse voltage (II/2)(KV)
- 4
- Rated impulse voltage (III/2)(KV)
- 4
- Rated impulse voltage (III/3)(KV)
- 4
-
Connection data-UL
- Rated voltage (UL/CUL Group B)(V)
- 300
- Rated current (UL/CUL Group B)(A)
- 20
- Rated voltage (UL/CUL Group D)(V)
- 300
- Rated current (UL/CUL Group D)(A)
- 10
-
Environment & Safety
- Finger protection (YES or NO)
- YES
- Operating temperature. max (°C)
- 120
- Operating temperature. min (°C)
- -40
-
UL Recognized
- Rated voltage (Group B)(V)
- 300
- Rated current (Group B)(A)
- 20
- Rated voltage (Group D)(V)
- 300
- Rated current (Group D)(A)
- 10
-
CUL Recognized
- Rated voltage (Group B)(V)
- 300
- Rated current (Group B)(A)
- 20
- Rated voltage (Group D)(V)
- 300
- Rated current (Group D)(A)
- 10
-
VDE Approval
- Rated voltage (V)
- 630
- Rated current (A)
- 18
-
EHDK1
Keycode For EHD series.
Orange color.
Using UL94-V0 class of insulation material. - Add
The web catalog is for reference only. Dinkle remains the right of product modification and engineering change of the design. The final product is made according to engineering drawing.
