• Short description
• Feed-through Bi-level, Stud Connection

• Long description
• Feed-through Bi-level, Stud Connection, Width：8.2mm, M3.5, 600V, 20A

• Category
• Feed-through Bi-level

• Color
• Refer to drawing

• Connection method
• Stud Connection

• Length (mm)
• 70

• Width (mm)
• 8.2

• Height (mm)
• 53

• Level
• Double level

• Connection points
• 4

• Insulation material
• PC

• Insulation material group
• Ⅲa

• Flame retardant rating , compliant with UL94
• V2

• Insulation resistance
• ≥1000MΩ at DC 500V

• Conductor material
• COPPER ALLOY

• Plating of conductor surface
• Tin PLATED

• Rated voltage (V)
• 630

• Rated current (A)
• 20

• Rated voltage (III/3)(V)
• 630

• Conductor cross section solid. min (mm²)
• 8

• Philips screwdriver size
• PH2

• Recommend tightening torque. min (N.m)
• 1

• Recommend tightening torque. max (N.m)
• 1.3

• Stripping Length (mm)
• The stripping length depends on the specification provided by the cable lug manufacturer.

• Mounting rail
• TS-35N、TS-35/15N

• End cover plate required
• YES

• Grounding connections
• NO

• Rated voltage (UL/CUL Group B)(V)
• 600

• Rated current (UL/CUL Group B)(A)
• 20

• Rated voltage (UL/CUL Group C)(V)
• 600

• Rated current (UL/CUL Group C)(A)
• 20

• Rated voltage (UL/CUL Group D)(V)
• 600

• Rated current (UL/CUL Group D)(A)
• 20

• Finger protection (YES or NO)
• YES

• Operating temperature. max (°C)
• 125

• Operating temperature. min (°C)
• -40

• Wire Range (Group B)(AWG)
• 26~12

• Rated voltage (Group B)(V)
• 600

• Rated current (Group B)(A)
• 20

• Wire Range (Group C)(AWG)
• 26~12

• Rated voltage (Group C)(V)
• 600

• Rated current (Group C)(A)
• 20

• Wire Range (Group D)(AWG)
• 26~12

• Rated voltage (Group D)(V)
• 600

• Rated current (Group D)(A)
• 20

• Wire Range (Group B)(AWG)
• 26-12

• Rated voltage (Group B)(V)
• 600

• Rated current (Group B)(A)
• 20

• Wire Range (Group C)(AWG)
• 26-12

• Rated voltage (Group C)(V)
• 600

• Rated current (Group C)(A)
• 20

• Wire Ranget (Group D)(AWG)
• 26-12

• Rated voltage (Group D)(V)
• 600

• Rated current (Group D)(A)
• 20
