P-830N

Barrier Terminal BlocksWire Terminal

Pitch : 8.00 /10.80 mm ,1.2x2.0mm, 85A

AccessoriesPDF Download Inquiry Add

  • General information
    • Short description
    • Barrier terminal blocks , Quick terminal blocks
    • Long description
    • Barrier terminal blocks , Pitch: 8.00 / 10.8mm , 1.2x2.0mm , 85A
    • Category
    • Quick terminal blocks
    • Pitch (mm)
    • 8.00 / 10.80
    • Pin demensions (Thickness x Width)(mm)
    • 1.2x2.0
  • Material information
    • Conductor material
    • Copper Alloy
    • Plating of conductor surface
    • Tinned
  • Connection data-IEC
    • Screw thread
    • M5
    • Slotted screwdriver size (Blade thickness x Width)(mm)
    • 1.0x5.5
    • Philips screwdriver size
    • PH2
    • Recommend tightening torque. min (N.m)
    • 2
    • Recommend tightening torque. max (N.m)
    • 2.4
  • VDE Approval
    • Rated current (A)
    • 85

The web catalog is for reference only. Dinkle remains the right of product modification and engineering change of the design. The final product is made according to engineering drawing.
