DKU15

NEMA Terminal BlocksRail Mounting

M3, 600V, 15A

AccessoriesPDF Download Inquiry Add

CAD data

  • General information
    • Short description
    • Feed-Through single level, Screw Connection
    • Long description
    • Feed-Through single level, Screw Connection, Width:7mm, M3, 600V, 15A
    • Category
    • Feed-Through single level
    • Pitch (mm)
    • 7
    • Color
    • Refer to drawing
    • Connection method
    • Screw Connection
    • Type of locking
    • Rail mounting
    • Length (mm)
    • 40.5
    • Width (mm)
    • 7
    • Height (mm)
    • 33.5(TS-35N)/41(TS-35/15N)
    • Number of poles
    • 01P
    • Number of positions
    • 01P
    • Level
    • 1
    • Connection points
    • 2
  • Material information
    • Insulation material
    • PC
    • Insulation material group
    • Ⅲa
    • Flame retardant rating , compliant with UL94
    • V2
    • Insulation resistance
    • ≥1000MΩ at DC 500V
    • Conductor material
    • COPPER ALLOY
    • Plating of conductor surface
    • Tin PLATED
  • Connection data-IEC
    • Rated voltage (V)
    • 630
    • Rated current (A)
    • 17.5
    • Rated voltage (III/3)(V)
    • 630
    • Rated impulse voltage (III/3)(KV)
    • 8
    • Conductor cross section solid. min (mm²)
    • 0.2
    • Conductor cross section solid.max (mm²)
    • 1.5
    • Conductor cross section stranded. min (mm²)
    • 0.2
    • Conductor cross section stranded. max (mm²)
    • 1.5
    • Screw thread
    • M3
    • Philips screwdriver size
    • PH2
    • Rated torque (N.m)
    • 0.6~1
    • Recommend tightening torque. min (N.m)
    • 0.6
    • Stripping Length (mm)
    • The stripping length depends on the specification provided by the cablelug manufacturer.
    • Mounting rail
    • TS-35N、TS-35/15N
    • End cover plate required
    • YES
    • Grounding connections
    • NO
  • Connection data-UL
    • Rated voltage (UL/CUL Group B)(V)
    • 600
    • Rated current (UL/CUL Group B)(A)
    • 15
    • Rated voltage (UL/CUL Group C)(V)
    • 600
    • Rated current (UL/CUL Group C)(A)
    • 15
    • Rated voltage (UL/CUL Group D)(V)
    • 600
    • Rated current (UL/CUL Group D)(A)
    • 15
    • Rated voltage (UL/CUL Group E)(V)
    • /
    • Rated current (UL/CUL Group E)(A)
    • /
    • Min. solid wire connection (AWG) acc. to UL/CUL
    • 26
    • Max. solid wire connection AWG acc. to UL/CUL
    • 14
    • Min. stranded wire connection AWG acc. to UL/CUL
    • 26
    • Max. stranded wire connection AWG acc. to UL/CUL
    • 14
  • Environment & Safety
    • Back of the hand protection (YES or NO)
    • YES
    • Finger protection (YES or NO)
    • YES
    • Operating temperature. max (°C)
    • 125
    • Operating temperature. min (°C)
    • -40
  • UL Recognized
    • Wire Range (Group B)(AWG)
    • 26~14
    • Rated voltage (Group B)(V)
    • 600
    • Rated current (Group B)(A)
    • 15
    • Wire Range (Group C)(AWG)
    • 26~14
    • Rated voltage (Group C)(V)
    • 600
    • Rated current (Group C)(A)
    • 15
    • Wire Range (Group D)(AWG)
    • 26~14
    • Rated voltage (Group D)(V)
    • 600
    • Rated current (Group D)(A)
    • 15
  • CUL Recognized
    • Wire Range (Group B)(AWG)
    • 26~14
    • Rated voltage (Group B)(V)
    • 600
    • Rated current (Group B)(A)
    • 15
    • Wire Range (Group C)(AWG)
    • 26~14
    • Rated voltage (Group C)(V)
    • 600
    • Rated current (Group C)(A)
    • 15
    • Wire Ranget (Group D)(AWG)
    • 26~14
    • Rated voltage (Group D)(V)
    • 600
    • Rated current (Group D)(A)
    • 15
